Rotary encoder ec11 is one of the more commonly used encoders. The commonly used models include rotary encoders ec11Y0, ec11I0, ec11E0, ec11A0, ec11E, ec11M, ec11A, ec11I, etc. I don't know how much you know about the safe use of the rotary encoder ec11? During use, if it needs to be disassembled, we first gently unplug the encoder spin-knitting wire from the encoder. Then loosen the M2.5 inner hexagonal bolt of the outermost ring of the encoder, but do not unscrew it. At this time, the encoder should be able to rotate flexibly. If it cannot be rotated, continue to loosen the M2.5 bolt until the encoder can rotate flexibly.

Then, loosen the M5 inner cubic bolt in the middle of the rotary encoder ec11 by two turns but do not remove it. Use an M10 bolt to screw into the middle threaded hole, and then apply a certain force to refuse to tighten the M10 bolt, and rotate when it reaches a certain force. Encoder ec11 will suddenly move. At this time, the taper shaft of rotary encoder ec11 has been separated from the taper hole of the main shaft. Unscrew the M10 bolt and then unscrew the M5 inner hexagonal bolt in the middle. Hold the rotary encoder ec11 while rotating it. The rotary encoder ec11 can be gently removed by moving it outwards.

(1)Rotary encoder ec11M

Rotary encoder ec11M_Product introduction:

　　 Rotary encoder ec11M is also called switch encoder, car encoder, etc. The rotary encoder ec11M is a direct plug-in encoder, which is different from the ec11E in that the bottom is a threaded handle. The rotary encoder ec11M has two types: 20 pulses and 20 positioning points, 15 pulses and 30 positioning points. The packaging is 250pcs/box, the adjustment shaft has full handle, half handle, etc., and the shaft length is between 9-30mm, customized according to customer requirements.

　　 Rotary encoder ec11M is mainly used in automotive electronics, multimedia audio, instrumentation, household appliances, smart home, computer peripherals, medical equipment and other fields. Mainly used for parameter control of frequency adjustment, brightness adjustment, temperature adjustment, and volume adjustment. Please note that the rotary encoder ec11M should not be stored in high temperature, humid and corrosive places. After unpacking, the unused products should be stored in a moisture-proof and poison-proof environment.

　　Encoder ec11M_Technical parameters:

　　 Operating temperature range: -30℃ to +80℃

　　 Storage temperature range: -40℃ to+85℃

　　 Rated voltage: DC 5V

　　 Full rotation angle: 360 degrees (no stop point)

　　Rotation life: 30000+200 Cycles

　　Contact resistance: ≤100mΩ

　　 Insulation resistance: 100MΩ or more

　　 Oscillation: ≤10mS press

　　Life: 20,000±200 times. (0.5 stroke)

　　 15,000±200 times. (1.5 stroke)

(2)Rotary encoder ec11E

Rotary encoder ec11E_Product introduction:

　　 Rotary encoder ec11E is also called switch encoder, because it is widely used in car DVD, car navigation, car audio and video, it is often called car encoder. At present, this encoder has two types: 20 pulses and 20 positioning points, 15 pulses and 30 positioning points. The rotary encoder ec11E is a side-insertion encoder, packaged in 250pcs/box, the adjusting shaft has a metal handle and a plastic handle, and the shaft length is between 9-30mm. The adjusting shaft has full handle, half handle, threaded handle and other types for your choice.

　　 Rotary encoder ec11E is mainly used for parameter control of frequency adjustment, brightness adjustment, temperature adjustment, and volume adjustment. Please note that the rotary encoder ec11E should not be stored in hot, humid and corrosive places. After unpacking, the unused products should be stored in a moisture-proof and poison-proof environment.

　　Rotary encoder ec11E_Technical parameters:

　　 Operating temperature range: -30℃ to +80℃

　　 Storage temperature range: -40℃ to+85℃

　　 Rated voltage: DC 5V

　　 Full rotation angle: 360 degrees (no stop point)

　　Rotation life: 30000+200 Cycles

　　Contact resistance: ≤100mΩ

　　 Insulation resistance: 100MΩ or more

　　 Oscillation: ≤10mS press

　　Life: 20,000±200 times. (0.5 stroke)

　　 15,000±200 times. (1.5 stroke)

(3)Rotary encoder ec11A0

Rotary encoder ec11A0_reference drawing:

Rotary encoder ec11A0_ product introduction:

　　 Rotary encoder ec11A0 is also called switch encoder, automobile encoder, etc. The adjustment shaft of the encoder has full handle, half handle, threaded handle and other types. Generally, it is mainly used for parameter control such as frequency adjustment, brightness adjustment, temperature adjustment, and volume adjustment.

　　 Rotary encoder ec11A0_ technical parameters:

　　 Operating temperature range: -30℃ to +80℃

　　 Storage temperature range: -40℃ to+85℃

　　 Rated voltage: DC 5V

　　 Full rotation angle: 360 degrees (no stop point)

　　Rotation life: 30000+200 Cycles

　　Contact resistance: ≤100mΩ

　　 Insulation resistance: 100MΩ or more

　　 Oscillation: ≤10mS press

　　 In the process of replacing the rotary encoder ec11, you need to pay attention. When installing the encoder, make sure that the rotor of the motor is different, otherwise the relative position of the rotor will be lost. If the relative position is lost, the old motor needs to use an oscilloscope to adjust the installation position of the rotary encoder ec11, and the new motor can judge and adjust the installation position of the rotary encoder ec11 according to the mark on the motor rotor shaft, which can be mechanically adjusted. You can also adjust the drive parameter MD1016 to set an offset value, but this method can only be used on 840D. After installing the fixing screws, be sure to loosen the top wire on the coupling to eliminate the jamming caused by the assembly stress, and turn the top wire flexibly by hand to die. Pay attention to the wiring sequence of the encoder, it may run over-current fault in reverse.
